Description
MOZA R9 V3 Bundle
The MOZA R9 V3 Bundle pairs the 9Nm wheelbase with a MOZA wireless racing wheel of your choosing, matched and ready to run out of the box. It suits a driver building a rig from scratch, or stepping up from a belt or gear driven wheel and replacing both parts at once.
As supplied, the bundle ships with the MOZA ESX racing wheel, which is officially licensed for Xbox. That makes this bundle Xbox and PC compatible as it comes. Choose a different wheel from the options above and the base becomes PC only, so pick the ESX if console play matters to you.
If you already own a MOZA wheel you are happy with, buy the MOZA R9 V3 wheelbase on its own instead and keep what you have.
Key features
- MOZA R9 V3 direct drive wheelbase and your choice of MOZA racing wheel
- Ships with the Xbox licensed ESX wheel as standard
- 9Nm peak torque direct drive servo motor
- Wheel options spanning GT, formula and road styles
- Wireless power and data between wheel and base, so no cable to the rim
- MOZA quick release on every wheel in the range
- 21-bit magnetic encoder resolving 2,097,152 steps per revolution
- 1000Hz USB refresh rate
- Aviation grade aluminium alloy housing
- Bottom and side mounting, with an optional table clamp
- Configured and updated through MOZA Pit House software
- 24-month manufacturer warranty on the wheelbase
Choosing your MOZA wheel
The wheel is the part you actually touch, and it is where this bundle is worth thinking about. Every option connects to the same R9 V3 base over the same wireless quick release, so the choice is about shape, materials and controls rather than compatibility.
Round GT style rims suit touring cars, GT racing and rally, and give you a full rim to work with. Formula style rims are flat-bottomed or butterfly shaped, put more controls under your thumbs, and suit open wheelers. Higher tier wheels add carbon fibre construction, more rotaries and encoders, and in some cases an integrated display.
The ESX is the entry point and the only Xbox licensed option. If you are unsure, it is the sensible starting wheel, and the quick release means changing to a second rim later takes seconds rather than a rebuild.
What the R9 V3 base brings
It is a 9Nm direct drive wheelbase with a 21-bit encoder and a 1000Hz refresh rate, in an aviation grade aluminium housing. Direct drive means the rim is coupled straight to the motor with no belts or gears, so what you feel is what the simulation calculated rather than a softened version of it.
Full specifications, mounting detail and the torque comparison against the rest of the MOZA range live on the MOZA R9 V3 wheelbase page.
What this bundle does not include
This bundle is a wheelbase and a wheel. Pedals are not included. If you need them, the MOZA R9 V3 + CRP2 Pedals Bundle adds load cell pedals and the MOZA R9 V3 + SRP2 Pedals Bundle adds the hybrid load cell set. Buying pedals as part of a bundle costs less than adding them later, and our sim racing pedals range covers the alternatives.
A mount is not included either. The base takes four bottom bolts or an optional side bracket, and fits the sim racing cockpits we stock along with most aluminium profile rigs. A table clamp is available if you are running a desk rather than a rig.
Which R9 V3 bundle suits you
There are four ways to buy it here, and the right one depends on how much of the rig you still need.
This bundle is base plus wheel. The MOZA R9 V3 + CRP2 Pedals Bundle adds the CRP2 load cell pedals alongside the ESX wheel. The MOZA R9 V3 + SRP2 Pedals Bundle does the same with the hybrid load cell set at a lower entry point. The MOZA R9 V3 Trucking Bundle is the most complete of the four: it swaps the racing rim for the TSW truck wheel and adds CRP2 pedals with the clutch and full length throttle plate, the truck wheel clamp and the multi-function stalks, for American or Euro Truck Simulator.
Setting up your bundle
The base and wheel arrive matched, so there is no pairing to work out. Connect the base to your PC, install MOZA Pit House, and run the calibration once.
Pit House is also where you set force feedback strength, tune damping and friction, adjust steering angle per car and save the result as a profile. Firmware updates are applied through the same software.
MOZA R9 V3 bundle frequently asked questions
What is included in this bundle?
The R9 V3 direct drive wheelbase and one MOZA racing wheel, which you select above. The standard price includes the ESX wheel. Pedals and a mount are not included.
Does this bundle work on Xbox?
Yes, as supplied. The standard ESX wheel is officially licensed for Xbox, and pairing it with the base makes the bundle Xbox and PC compatible. The other wheels in the range are PC only, so choose the ESX if you race on console.
Which wheel should I choose?
Round GT rims suit touring, GT and rally driving. Formula rims suit open wheelers and put more controls in reach. Higher tier wheels add carbon construction, more encoders and in some cases a display. Every one of them fits the same base through the MOZA quick release.
Can I change the wheel later?
Yes. The quick release means swapping rims takes seconds and needs no tools. Adding a second wheel later is a common upgrade path.
Do I need pedals as well?
Yes, if you do not already own a set. This bundle does not include them. The CRP2 pedal bundle and SRP2 pedal bundle include a set and cost less than buying pedals separately afterwards.
Is the bundle cheaper than buying the parts separately?
Yes. The wheel is discounted against its standalone price when bought as part of the bundle.
What do I need to mount it?
Four bottom bolts into a rig, or an optional side bracket. A table clamp is available for desk setups, though a rigid cockpit will always give you more of what the base can do.
How hard is the setup?
Connect the base to your PC, install MOZA Pit House, and run the calibration once. Firmware updates go through the same software.
How long is the warranty?
MOZA covers the wheelbase for 24 months and the power supply for 12 months. Gamer Gear Direct handles warranty support locally, and your rights under Australian Consumer Law apply in addition.
Who is this bundle for?
Drivers who need a base and a wheel together: a first direct drive setup, or a step up from a belt or gear driven wheel where both parts are being replaced at once.
Specifications
MOZA R9 V3 Direct Drive Wheelbase
FFB Drive System
Direct Drive
Communication Method
Wireless between wheel and wheelbase
Max Wheel Rotation
Limitless
Housing Material
Aviation Grade Aluminium Alloy
Colour
Black
Peak Torque
9 Nm
Peak Power
180W
Input Voltage
110V~220V AC to 36V DC
USB Refresh Rate
1000Hz
Encoder Resolution
21-bit (2,097,152 steps per revolution)
Indicator
YES
App Functions
Supported
Quick Release
Supported
Connection Ports
Power, DC Input, E-stop, USB, Dash
Accessories
User manual, Warranty card, Power supply, USB cable, Toolkit
Mounting Method
Bottom mount
Side Mount Option
With optional side mount bracket
Desk Clamp
Optional
Emergency Stop Switch
Optional
Online Firmware Upgrade
Applicable
Firmware Update
Applicable
Dimension (L x W x H)（mm）
240*157*124
Weight
6.8kg
MOZA ESX Racing Wheel
Grips
Microfibre Leather
Face Plate Material
Aluminium Alloy
Shifter Paddle Material
Aluminium Alloy
Size
280mm
Buttons
22
LED Lamp Beads
10
Intelligent Telemetry
Supported
Fully Adjustable RPM LEDs through MOZA Pit House
Supported
Release Method
MOZA Quick Release
CS V2P Racing Wheel
Grips
Microfiber Leather
Face Plate Material
Aluminium Alloy
Back Plate Material
Aluminium Alloy
Shifter Material
Forged Carbon Fibre
Size
13 Inches
Magnetic Shifters
2
Mechanical Key Buttons
6
Joysticks
2
Rotary Encoders
2
LED RGB Light Beads
10
Choice of Colours
7
Intelligent Telemetry
Yes
Fully Adjustable RPM LEDs through MOZA Pit House
Supported
Release Method
MOZA Quick Release
Communication Method
Wireless
Shifter Sensor
Non-contact Photoelectric Sensor
KS Racing Wheel
Size
300mm standard GT wheel
Paddle Material
Aluminium alloy
Magnetic Shifter Paddles
2
Clutch Paddles
2
Luminous Short Travel Buttons
10
Joysticks (depressible)
2
Thumb Encoders
2
Rotary Encoders
3
High Brightness LEDs
10
LED Colours
8
Intelligent Telemetry
Supported
Fully Adjustable RPM LEDs through MOZA Pit House
Supported
Release Method
MOZA Quick Release
Communication Method
Wireless or via Industrial Conductive Slip Ring
Paddle Sensor
Non-contact Hall Sensor
Dual Clutch Paddle Modes
Combined Axis/Independent Axis/button
Knob Modes
Button or dial
Compatibility
All MOZA wheelbases and 3rd party wheelbases
3rd party base expansion port
Supported
RS V2 Racing Wheel
Size
330mm
Grips
Genuine Leather
Face Plate Material
Forged Carbon Fibre
Back Plate Material
Aluminium
Shifter Paddles Material
Forged Carbon Fibre
Shifter Paddles
Magnetic
Buttons
10
Button Light
Yes
Choice of Colours
8
Button Type
Mechanical Buttons
Universal Joysticks
2
Rotary Encoders
2
Communication Methods
Wireless & Wired
Release Method
MOZA Quick Release
Quick Release Material
Aluminium
Shift Light Indicator
Yes
Shift Light Customization
Yes
Shift Light Colour Options
7
Shift Light Mode Switch
Yes
RPM Indicator
Yes
GS V2P GT Racing Wheel
Grips
Perforated Microfiber Leather
Wheel Rim & Face Plate Material
5mm-thick Forged Carbon Fibre
Back Plate Material
Carbon Fiber Reinforced Composite
Shifter Paddle Material
3 mm-thick Forged Carbon Fibre
Size
300mm Diameter Standard Racing Wheel
Magnetic Shifter Paddles
2
Clutch Paddles
2
Luminous Mechanical Buttons
10
Rotary Encoders
5
Thumb Encoders (depressible)
2
Joysticks
2
LED Lamp Beads RGB
10
Choice of colours
8
Intelligent Telemetry
Yes
Fully Adjustable RPM LEDs through MOZA Pit House
Supported
Release Method
All-aluminium MOZA quick release
Power Supply
Wireless
Communication Methods
Wireless and Wired
Paddle Sensor
Non-contact Hall Sensor
Dual Clutch Modes
Combined Axis/Independent Axis/button
FSR Racing Wheel
Size
280mm
Digital Dash Size
4.3 Inches
Digital Dash Resolution
800*480
Grips
Perforated Leather
Face Plate Material
5mm-thick Toray Carbon Fiber
Shifter Paddles Material
3 mm-thick, Forged Carbon Fiber
Back Plate Material
Aviation-grade Aluminium
Magnetic Shifter Paddles
2
Dual Clutch Paddles
2
Luminous Mechanical Buttons
10
Thumb Encoders (depressible)
2
Rotary Encoders
5
LED Lamp Beads
10
Choice of colours
7
Intelligent Telemetry
Supported
Fully Adjustable RPM LEDs through MOZA Pit House
Supported
Release Method
MOZA Quick Release
Communication Method
Wireless / USB (Requires the use of the MOZA universal HUB in order to connect via USB.)
Paddle Sensor
Photoelectric Sensor
Dual Clutch Paddle Mode
Combined Axis/Independent Axis/button
What’s In The Box?
1x MOZA R9 V3 direct drive wheelbase
1x MOZA ESX racing wheel (or choose from the wheel options above)
1x MOZA quick release
1x Power supply
Cables
User manual
