The standard M8 fixing on an aluminium rig is 20mm long, and it works until you put something thicker in the joint. Add a plate, stack two brackets, or fit a spacer, and 20mm no longer reaches far enough into the T-nut to hold properly.
This is the same screw 5mm longer. M8 x 25mm, hex head, six to a set, and it is the length Trak Racer specifies where thicker plate is involved across the TR8020 range.
The rule is simple. Measure the total thickness of everything the screw passes through, then add enough length for full thread engagement in the nut. If the screw bottoms out before the joint is tight, it is too long. If it engages only a couple of threads, it is too short and the joint will fail.
Going up in 5mm steps is usually enough to solve it. If 25mm still does not reach, the M8 x 30mm hardened set is the next size, and the 5mm spacer kit covers the opposite problem of a part that needs lifting clear. All three lengths are stocked in our racing simulator accessories range.
"Nine times out of ten a fastener problem on a rig build is a length problem. Keep 20mm and 25mm both in the drawer and most jobs are covered. Never make a short screw work by leaving the joint slightly loose."
- Blake Sterling, Founder & CEO, Gamer Gear Direct
Only in length. It is the same M8 hex head screw, 5mm longer, for joints where the parts being clamped are thicker than a standard bracket.
Six.
Measure the total thickness of the parts the screw passes through. If a 20mm screw only catches a few threads in the nut, step up to 25mm.
Thread size: M8
Length: 25mm
Head type: Hex
Set contents: 6 screws
Application: Thicker plate and stacked assemblies
Warranty: 2 years
6 x M8 x 25mm hex screws
This Trak Racer screw set is backed by a 2-year limited manufacturer warranty covering materials and manufacturing under standard residential use.
Normal wear and tear sits outside the warranty. Every product is 100% genuine, sourced directly from Trak Racer's official distributors, and our Australian simulation team is only a call or email away.
