Description
Same torque, rebuilt underneath
The Simucube 3 Pro is rated at 25Nm, the same as the Simucube 2 Pro. That is deliberate, and it is the point: this generation is not about more power, it is about what the base does with the power it has.
The sensor moves from 22-bit to 23-bit absolute, eight million steps of rotation. The control algorithm was rewritten from scratch, every base is laser scanned so the firmware carries a digital twin of that individual unit, and telemetry-based effects such as road texture, ABS feedback and RPM are new to the 3 series.
Key features
- 25Nm maximum torque
- 23-bit absolute angle sensor
- Direct drive optimised SPM motor
- Control box with emergency torque off
- Link Quick Release fitted to the base
- Simucube Tuner 3.0
What the 3 series actually changes
Three things, in Simucube's own terms. The motor controller and the control algorithm were redesigned. Each wheelbase is laser scanned during manufacture, creating what they call a digital twin inside the code, which is how they tune each unit rather than each model. And the software gained telemetry-based effects, so road texture, ABS and RPM come from the game's data rather than being synthesised from force alone.
None of that shows up as a torque number, which is why the spec sheet looks familiar. Our direct drive wheelbases pages set the generations side by side.
The control box, and the safety it carries
A control box is included and it is not optional: the Simucube 3 will not switch on without it connected. It carries the torque off button, an emergency stop: press to activate and rotate clockwise to release.
It also carries an encoder, so you can adjust feedback strength and other parameters while you are driving rather than stopping to open software. The LED tells you the state of the base, including torque off, safe mode and device fault.
What you need alongside it
The Link Quick Release wheelbase side is pre-fitted. If your steering wheel is a Simucube 3 compatible model it already has the wheel side. Carrying a Simucube 2 wheel across needs the Link Quick Release, and a formula wheel on a 50.8mm bolt pattern needs the 50.8 to 70mm adapter on top.
The base runs on the Simucube Link network rather than a direct USB connection, so it needs a Simucube Link Hub. One hub serves a whole rig, and adding a second Link device such as an ActivePedal needs an Ethernet switch as well.
Our expert take
"Do not buy a Simucube 3 Pro expecting more grunt than a 2 Pro, because on paper there is none. Buy it for the sensor resolution, the new algorithm and the telemetry effects. And order the Link Hub at the same time, because the base genuinely will not run without one and it does not come in the box."
- Blake Sterling, Founder & CEO, Gamer Gear Direct
Frequently asked questions
Is a Link Hub included?
No. One Simucube Link Hub is required to operate, and it comes in a separate box. One hub covers every Simucube Link device on your rig.
Is it more powerful than the Simucube 2 Pro?
No. Both are rated at 25Nm. The differences are the 23-bit sensor, the rewritten control algorithm, the per-unit laser scanning and the telemetry-based effects.
Can I use my Simucube 2 steering wheels?
Yes. All Simucube wireless wheels are compatible. You will need a Link Hub for the data and a Link Quick Release for the mechanical fit.
Does it connect over USB?
Not directly. It connects by RJ45 to a Simucube Link Hub, which takes one USB port on the PC. There is no USB passthrough on the base.
Specifications
Maximum torque: 25Nm
Angle sensor: 23-bit absolute, 8,000,000 steps
Motor: High response speed, direct drive optimised SPM
Wheelbase dimensions: 135 x 135 x 303mm
Weight: 11kg
Mounting: Front and bottom
Mounting hole pattern: 135mm and 78.4mm diameter
Flange centring feature: 110mm diameter
Power supply: 360W, 450W peak, included
Connection: RJ45 to Simucube Link Hub
Simucube Link Hub: Required to operate, not included
Link Quick Release: Wheelbase side pre-installed, wheel side sold separately
Control box: Included, carries the emergency torque off
Software: Simucube Tuner 3.0
Warranty: 3 years
What's In The Box?
1 x Simucube 3 Pro wheelbase
1 x power adapter
1 x RJ45 cable
1 x AC power cord
1 x control box
1 x quick start guide
Fastener kit with M5, M6 and M8 bolts, washers and t-slot nuts
