MOZA Pit House Setup Guide: How to Download, Install and Configure
|
MOZA Pit House is the official Windows software that controls every MOZA sim racing device. It handles force feedback tuning, device calibration, firmware updates, button mapping, LED configuration and custom profiles, all from one application. If you've just received your first MOZA product, or you're expanding your setup and need to get everything running together, this is the guide to start with.
Everything below is based on official MOZA support documentation. All steps reflect the current Pit House release as of publication.
What you'll need: A Windows PC (x86 or x64). An internet connection for the online installer, or the offline installer downloaded in advance. Your MOZA device connected via USB. The setup process typically takes 10 to 15 minutes.
Downloading MOZA Pit House
The official download page is at MOZA's support site. There are three versions to choose from, depending on your situation [1]:
- Online installer - The smaller download. Requires an internet connection during installation to pull the latest files. This is the recommended option for most users, as it always installs the current release.
- Offline installer (v1.3.5.36) - A larger, self-contained package that installs without internet access. Useful for systems without a reliable connection, but you may need to run an update through Pit House after installation to reach the latest version.
- Legacy version (v1.2.2.6) - For older computers that do not meet the system requirements of the current release. Use this only if the standard installer fails to run on your system.
A separate offline firmware updater and rollback tool are also available on the same page, for situations where firmware needs to be managed outside of Pit House itself.
Installing MOZA Pit House
Run the installer you downloaded. Pit House installs by default to C:\Program Files (x86)\MOZA pit house [2]. You can change the install location during setup if needed.
The installer may offer optional components including Visual C++ redistributables and font libraries. These are standard Windows dependencies. If prompted, install them unless you know they are already present on your system.
Once installed, launch Pit House from the Start menu or the desktop shortcut.
First Run: Connecting Your Devices
The first time Pit House opens, it will prompt you to set up your game library. You can point it at your Steam folder and any custom game directories. This lets Pit House launch your sim titles directly and apply the right profile automatically when you open a game.
Connect your MOZA device via USB. The device panel on the main screen will show connected devices in colour and disconnected devices in grey. If a device appears grey after connecting, check the USB cable is seated firmly and try a different USB port [2].
Each connected device gets its own configuration panel in the left sidebar. Click any device to open its settings.
Updating Device Firmware
MOZA recommends checking for a firmware update the first time you connect a device. Outdated firmware can affect calibration accuracy and software compatibility.
To update [2]:
- Select your device in Pit House.
- Click Check Update in the firmware section. Pit House will check the current firmware version against the latest available release.
- If an update is available, the status changes to Updatable. Click to initiate the upgrade.
- The status moves through Upgrading to Success when complete. Do not disconnect the device during this process.
- If the update fails, click to retry. A persistent failure may indicate a hardware issue and should be reported to MOZA support.
Firmware updates for each device class are independent. Update your wheelbase, steering wheel and pedals separately if you have multiple devices.
Configuring Each Device in Pit House
Pit House exposes different settings for each device class. Here is what each section controls [2][3]:
Wheelbase
The wheelbase settings are where most force feedback tuning happens. Key parameters include force feedback intensity, maximum steering angle, centering spring strength, damping ratio, hand-off protection (which cuts force feedback if the wheel is grabbed beyond a set point), and road sense equalizer (which adjusts the balance between detailed road texture and larger directional forces). Pit House offers basic and professional modes: basic mode presents simplified sliders, while professional mode exposes the full parameter set.
Steering Wheel
Rim configuration covers the LED display, including colour mapping by RPM range, brightness level, RPM thresholds for shift light activation, and speed-following modes that adjust LED behaviour based on vehicle speed. Button detection covers horn activation, paddle shifter sensitivity, rotary knob behaviour and rocker switch assignments.
Pedals
Each pedal axis (throttle, brake, clutch) is calibrated individually. You set the start and end points of the pedal travel, choose a stroke-length preset for your physical setup, and select a response curve: linear, progressive, or a custom curve you draw manually. This is where load-cell brake sensitivity is configured if you're using CRP2 or compatible pedals with a load cell.
Shifter and Handbrake
MOZA shifters and handbrakes connect to a compatible MOZA wheelbase and are calibrated through Pit House rather than configured separately. Once connected to the wheelbase, Pit House detects the accessory and presents its calibration options alongside the other devices [3].
Dashboard
For MOZA dashboards or wheels with integrated displays, this section controls screen brightness and the telemetry display style, including which data is shown and how it is visualised.
Custom Profiles and Per-Game Settings
Pit House supports multiple saved profiles. You can create a separate profile for each sim title you run, each with its own force feedback intensity, steering angle and response curves. When a game from your configured game library is launched, Pit House can switch to the matching profile automatically.
This is particularly useful if you drive across different disciplines. A rally title typically benefits from a wider steering angle and heavier damping than an open-wheel title, and a profile per game means you do not need to readjust settings each time you switch.
Troubleshooting Common Issues
| Issue | What to check |
|---|---|
| Device shows grey in Pit House | Check USB connection. Try a different port. Ensure the device is powered on (wheelbases have an independent power supply). |
| Firmware update fails repeatedly | Use the offline firmware update tool from the MOZA downloads page. If that also fails, contact MOZA support. |
| Force feedback feels weak or wrong | Check in-game FFB settings as well as Pit House. Many titles have their own FFB strength slider that interacts with Pit House settings. Set in-game FFB to 50% as a starting point, then adjust in Pit House. |
| Pedal axis reading is off centre | Recalibrate the axis by setting new start and end points in the Pit House pedal section. Press the pedal fully before confirming the end point. |
| Pit House does not detect game launch | Confirm the game folder path is added to your game library in Pit House settings. Steam games require the Steam library root folder, not the individual game subfolder. |
